    4 * 800W Class H Analogue Amplifier Fixed Installation Digital Audio Amplifier

    Ask Lasest Price
    Brand Name : HOT DEVICES
    Model Number : HD-4.08
    Certification : CE,ROHS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 2000 pcs/month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    4 * 800W Class H Analogue Amplifier Fixed Installation Digital Audio Amplifier


    Analog Audio Amplifier/ 4 Channel 4*800W Class H Analogue Amplifier For Fixed Installations


    Quick Detail:


    4-channel analogue amplifier, 5 models, from 4x300W@8Ω to 4x800W@8Ω, all 2U, excellent quality, high stability, suitable for fixed installation and living event for main speakers and small line array speaker system.


    Description:


    Are there some analogue power amplifiers with professional circuit design, good interior structure, excellent sound quality, and extraordinary stability? Yes, HD-4.03, 4.04, 4.05, 4.06, 4.08(4x300W,400W,500W,600W,800W@8ohm) are the best option we can offer you.


    They are one series NEVER-STOP Class AB and H analogue power amplifiers.


    Want high resolution pictures, have further questions and want to know prices? For a fast and easy communication, please contact us at Whatsapp and our number for Whatsapp is +86 13512754579. Our FACEBOOK page: MasterSound.GuangZhou. Or you can send your detailed requirements to

    our mailbox info@master-sound.cn.


    Applications:


    Living event. night club, disco and other applications with high requirements on sound quality and stability


    Specifications:


    HD-4.03HD-4.04HD-4.05
    8Ω Stereo Output:4x300W4x400W4x500W
    4Ω Stereo Output:4x450W4x600W4x750W
    8Ω Bridge:2x700W2x1000W2x1300W
    Class:ABABH
    Frequency Response:20Hz-20KHz20Hz-20KHz20Hz-20KHz
    THD+N:<0.01%<0.01%<0.01%
    S/N Ratio:105dB105dB105dB
    Damping Factor:450:1450:1500:1
    Input Sensitivity:0.775V /1V/1.44V0.775V /1V/1.44V0.775V /1V/1.44V
    Input Impedance:20KΩ BALANCED, 10KΩ UNBALANCED

    20KΩ BALANCED,

    10KΩ UNBALANCED

    20KΩ BALANCED,

    10KΩ UNBALANCED

    Item Dimensions(mm):483x460x89 (2U)483x460x89 (2U)483x460x89 (2U)
    Net Weight(kgs):192226
    HD-4.06HD-4.08
    8Ω Stereo Output:4x600W4x800W
    4Ω Stereo Output:4x900W

    4x1200W

    8Ω Bridge:2x1800W2x2000W
    Class:HH
    Frequency Response:20Hz-20KHz20Hz-20KHz
    THD+N:<0.01%<0.01%
    S/N Ratio:105dB105dB
    Damping Factor:550:1550:1
    Input Sensitivity:0.775V /1V/1.44V0.775V /1V/1.44V
    Input Impedance:20KΩ BALANCED, 10KΩ UNBALANCED20KΩ BALANCED, 10KΩ UNBALANCED
    Item Dimensions(mm):483x460x89 (2U)483x460x89 (2U)
    Net Weight(kgs):30.533

    Competitive Advantage:


    good sound quality, high stability, fixed with good electronic components
