150W Conference Room Audio Systems Good Sound For Disco , 8ohm
Quick Detail:
Plywood loudspeakers with beautiful and compact cabinet design,
high quality sound, rotatable and strong fiberglass horn, and M8
flying points for multipurpose applications. Waterproof version
loudspeakers available for outdoors applications.
Description:
MQ series full range loudspeakers' cabinet design is very
special--the cabinet(except top and bottom board) is constructed by
one whole plywood board after special production processes,but not
constructed by seperate boards. The special design makes the
cabinet light, compact and strong. 15mm thick plywood for full
range loudspeakers, and 18mm thick plywood for subwoofers.
Some loudspeakers are fixed with LF driver with UKM paper
diaphragm, and some fixed with HF driver with titanium diaphragm
from B&C’s Chinese supplier. MQ-10 is fixed with original
CELESTION driver. MQ-8,10,12,15 are fixed with rotatable and strong
fiberglass horn. The pole mount in the loudspeakers make stand and
pole support possible. M8 flying points are for fixed installation.
White/Black finish available for options. Applications for MQ
series loudspeakers: night club, disco, conference, pub, church,
living show.......
To meet the requirements of outdoors use, we launched waterproof
version MQ series loudspeakers. Following steps show how we make
the waterproof loudspeaker: make empty cabinet --> daub resin on
cabinet --> stick fiberglass on resin ---> daub resin on
fiberglass again --> sanding resin and fiberglass -->
painting --> spray waterproof glue on the LF driver paper
diaphragm à stick foam behind the mesh grille.
More and more customers are selling our MQ series loudspeakers and
MQ is our most popular loudspeaker series. With beautiful mesh
grille design, professional, compact and multipurpose cabinet
design, and good sound quality, MQ series loudspeakers enjoy a very
good reputation.
Applications:
pub, church, conference, background music, night club, disco, and
living event.
Specifications:
Components: 1"+6.5"
Nominal Impedance: 8ohm
Power Handling: 150W
Frequency Response: 75Hz-18KHz(±3dB)
Sensitivity(1W/1M): 100dB
Max. SPL: 121dB(continuous), 128dB(peak),
Dispersion(HxV): 90 °x50 °
Connector: SPEAKON
Flying Hardware: M8 rigging point
Dimensions(HxWxD): 430x243x227mm
Net Weight(Kg): 7
Competitive Advantage:
Compact cabinet, beautiful cabinet design, plywood material, high
quality drivers inside, excellent sound quality
